Caliper
2015017 Calipers
Has the clearance needed for measuring around just about any lens blank or frame. Stainless Steel and Brass.
2015016 Calipers
Constructed of corrosion resistant brass and stainless steel.
Has extra deep and extra wide jaws for use on lenses up to 86mm
in diameter and 15mm thick. Scale is in 10th millimeter increments.
Soft spring and Delrin tipped jaws protect lens material. 7-3/8" long.
New Feature. Vinyl Grip throat for extra protection It do not give scratch
to the lense.
Length: approx. 185MM
Weight: approx. 110 g
Material: Stainless steel
Finish: Dull mate
Throat: Cushion Grip
Movement: spring action
2015001 Calipers
Constructed of corrosion resistant brass and stainless steel.
Has extra deep and extra wide jaws for use on lenses up to 86mm
in diameter and 15mm thick. Scale is in 10th millimeter increments.
Soft spring and Delrin tipped jaws protect lens material. 7-3/8" long.
New Feature. Vinyl Grip throat for extra protection It do not give scratch
to the lense.
Length: approx. 185MM
Weight: approx. 110 g
Material: Stainless steel
Finish: Dull mate
Throat: Cushion Grip
Movement: spring action
2015003 Degree Gauges
Lightweight, sensitive gauges made of polished steel,
with easy to read brass indexes. Combination Adjustable
is sold with: 1/2" jaw, with adjustable point for close
tolerance work.
Length: approx. 160MM
Weight: approx. 46 g
Material: Stainless steel
Finish: Dull mate
Movement: spring action
2015002 Calipers
MEASURES UP TO 25MM
THICK LENSES IN 1/5MM
GRADUATIONS. EASY TO
CALIBRATE. PRECISION
CONSTRUCTED OF STAINLESS
Length: approx. 190 MM
Weight: approx. 87 g
Material: Stainless steel
Finish: Dull mate
Movement: spring action
2015008 Calipers
BRASS SLIDING GAUGE MEASURES
MILLIMETERS & INCHES
ACCURATELY. SLIDING GAUGE IS
GREAT FOR MEASURING STONES, Capacity (100 mm).
Length: approx. 115MM
Weight: approx. 60 g
Material: Brass
Finish: Dull mate
2015009 Calipers
Brass combination inch and millimeter gauges. Capacity 3" (80 mm).
Graduations by 1/16ths and 1.0 mm.
Length: approx. 100MM
Weight: approx. 52 g
Material: Brass
Finish: Dull mate
2015010 Calipers
BRASS SLIDING GAUGE
MEASURES MILLIMETERS &
INCHES ACCURATELY.
MEASURES UP TO 100MM (31/4).
Length: approx. 115 MM
Weight: approx. 70 g
Material: Brass
Finish: Dull mate
2015004 Calipers
Angular measurement (Möltgen)
STAINLESS STEEL MEASURING
RANGE 0 – 180MM, IN 1MM
INCREMENTS. TWO 180°
SCALES THAT READ IN
OPPOSITE DIRECTIONS. NON
LOCKING FRICTION ARM.
Length: approx. 185MM
Weight: approx. 98g
Material: Stainless steel
Finish: Dull mate
2015005 Calipers
A SIMPLE & ACCURATE DEVICE TO
MEASURE JOINT'S RANGE OF
MOTION. STAINLESS STEEL
CONSTRUCTION. TWO 180°
SCALE IN OPPOSITE DIRECTION
FOR CONVENIENT READING.
Length: approx. 300 MM
Weight: approx. 204 g
Material: Stainless steel
Finish: Dull mate
2015012 Distometer
The Device Designed to measure the VERTEX Distance Between The Cornea and Trial OR Spectacle Lenses
Length: approx. 5 inch
Weight: approx. 54 g
Material:
Finish: Black
2018003 PD RULER
Straight, stainless steel 155 millimeter and 6 1nch ruler .
Length: approx. 117MM
Weight: approx. 15g
Material: Stainless steel
Finish: Dull mate
2015006 castroviejo gauge
EYE CASTROVIEJO CALIPER,
Bend and straight
3-1/4", GRADUATED 0-15 CM, 31/4"(8.2
CM).
STAINLESS
Length: approx. 95 MM
Weight: approx. 25 g
Material: Stainless steel
Finish: Dull mate
